R82 Caribou
The Caribou is a versatile paediatric standing aid that supports prone, upright, or supine standing positions. The Caribou is an ideal solution for children who have limited head and trunk control, or limited range of motion.
The Caribou is designed to support children in standing strong every day, offering a versatile solution that adapts to individual needs, whether in a prone or supine position. Its tilt function and extensive range of accessories allow for precise customisation, helping the child build strength and improve posture. By providing a stable and comfortable base, the Caribou enables participation in daily activities alongside peers. This adaptable standing frame grows with the child, ensuring consistent support and creating opportunities for engagement and development in any environment.
Features
-
Features
Anatomic design and soft mouldable PU
Soft PU material for optimum comfort. The shape can be moulded to the body using additional wedges to shape the PU. The Caribou is designed with smooth edges for better safety and it is easy to clean.
-
Features
Interchangeable accessories
Caribou has a rage of different accessories that are easily interchangeable for carers' convenience.
-
Features
Easy tilt
The Caribou is supplied with an easy tilt mechanism, which allows the carer to have both hands free.
-
Features
Easy transfer
The Caribou tilts from vertical to horizontal. The horizontal position makes it easier for the carer and a more pleasant experience for the user to be placed into position. The Caribou is designed with a raised frame for easy use of floor hoist.
Variants
| Size 1 | Size 1 (w/ power) | Size 2 | Size 2 (w/ power) | Size 3 | Size 3 (w/ power) | Size 4 | Size 4 (w/ power) | |
|---|---|---|---|---|---|---|---|---|
| Item number | 860101 | 860101-EL | 860102 | 860102-EL | 860113 | 860103-EL | 860114 | 860104-EL |
| Angling (°) | 0-87 | 0-87 | 0-87 | 0-87 | 0-87 | 0-87 | 0-87 | 0-87 |
| Approximate total user height (mm) | 850-1120 | 850-1120 | 980-1290 | 980-1290 | 1250-1560 | 1250-1560 | 1530-1840 | 1530-1840 |
| Foot plate angle (°) | (-20) - 20 | (-20) - 20 | (-20) - 20 | (-20) - 20 | (-20) - 20 | (-20) - 20 | (-20) - 20 | (-20) - 20 |
| Length (mm) | 750 | 750 | 920 | 920 | 1110 | 1110 | 1110 | 1110 |
| Maximum rated load (kg) | 62.5 | 64.5 | 86 | 87.5 | 112.5 | 114.5 | 137 | 139 |
| Maximum user mass (kg) | 40 | 40 | 60 | 60 | 80 | 80 | 100 | 100 |
| Overall height, horizontal (mm) | 700 | 700 | 700 | 700 | 800 | 800 | 800 | 800 |
| Overall height, vertical (mm) | 460-570 | 460-570 | 530-640 | 530-640 | 680-790 | 680-790 | 880-990 | 880-990 |
| Overall width (mm) | 510 | 510 | 570 | 570 | 650 | 650 | 750 | 750 |
| Static stability downhill (°) | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
| Static stability sideways (°) | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
| Static stability uphill (°) | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
| Total mass (kg) | 20.5 | 22.5 | 24 | 25.5 | 30.5 | 32.5 | 35 | 37 |
Overall height configuration: Standard product and top plate (measured from the floor)
Washing instructions
The product is CE marked
Options
Accessories
Documents
Download of user manuals are intended for expedient purpose only. The products in reference may be subject to change without prior notice and reader’s discretion is advised to ensure coherence with product version and article number as well as the appropriate translation.
Videos
How to mount the tray top cover
