R82 x:panda
The x:panda is a multi-adjustable dynamic seat, developed to establish an ideal seating position for children and youngsters living with a disability.
The x:panda is designed to move with the child, offering a seating experience that encourages natural motion. Its dynamic back absorbs extension and gently guides the child back to a supportive, neutral position. This responsive design maintains stability and comfort throughout the day, reducing the need for frequent repositioning. By accommodating movement, the child can focus energy on interacting with their environment. It creates a reliable foundation that supports independence and participation in daily activities.
-
x:panda video
See instruction on how to assemble the multi-adjustable dynamic seat x:panda.
Features
-
Features
Dynamic back
The x:panda has a unique dynamic back that absorbs the energy of extension and returns the child to upright sitting without compromising pelvic positioning.
-
Features
Multi-adjustable
Overlap in sizing means that the starting option always offers the maximum growth potential coupled with individual leg positioning.
-
Features
Growth
Individual growth in width, depth and back height to extend the life of the seat and accommodate the greatest range of sizes.
-
Features
Dynamic back recline
The point for rotation (recline of the back) is close to the axis of the hips which means that the back support maintains the correct position and minimises shear.
Variants
| Size 1 | Size 2 | Size 3 | Size 4 | |
|---|---|---|---|---|
| Item number | 891011x-01 | 891012x-01 | 891013x-01 | 891014x-01 |
| Abduction angle each leg, size 1 in smallest position (°) | 0 - 8 | - | - | - |
| Abduction angle, each leg (°) | 0 - 15 | 0 - 15 | 0 - 15 | 0 - 15 |
| Armrest to seat distance (mm) | 100-165 | 100-165 | 100-165 | 100-165 |
| Back width, top of backrest (mm) | 230 | 280 | 330 | 350 |
| Backrest angle (°) | (-5) - 30 | (-5) - 30 | (-5) - 30 | (-5) - 30 |
| Backrest height (mm) | 270-370 | 320-420 | 350-470 | 500-710 |
| Effective seat depth (mm) | 160-260 | 220-330 | 260-390 | 390-530 |
| Effective seat width (mm) | 160, 200, 240 | 200, 240, 280 | 260, 310, 360 | 340, 400, 460 |
| Front location of arm rest structure (mm) | 140 | 140 | 180 | 350 |
| Mass device (kg) | 6.5 | 8.5 | 11 | 13 |
| Maximum rated load (kg) | 38.5 | 40.5 | 73 | 95 |
| Maximum user height (mm) | 1050 | 1280 | 1430 | 1800 |
| Maximum user mass (kg) | 30 | 30 | 60 | 80 |
| Maximum user mass in transportation (kg) | 30 | 30 | 60 | 75 |
| Minimum User Height (mm) | 650 | 850 | 1000 | 1390 |
| Width thighs (mm) | 70, 90, 110 | 100, 120, 140 | 120, 145, 170 | 130, 190, 250 |
Abduction angle each leg for size 1 in the smallest position 0° - 8°.
Washing instructions
The product is CE marked
Options
Accessories
Documents
Download of user manuals are intended for expedient purpose only. The products in reference may be subject to change without prior notice and reader’s discretion is advised to ensure coherence with product version and article number as well as the appropriate translation.
Videos
How to mount a table
How to assemble the x:panda
R82 x:panda seat mount and dismount
How to do Seat and Back Adjustments
