R82 Rabbit Up
The Rabbit Up is an adaptive standing frame suitable for children with varying needs. This standing frame supports an upright or prone standing position, providing optimal flexibility and adaptability for the child's needs.
The Rabbit Up empowers children to explore their world from an upright standing, mobile position. With optional driving wheels, it offers the freedom to move about independently, stimulating the senses and fostering active participation in daily life. This versatile and adaptive standing frame provides the support needed to stand tall, while allowing the child to be an active participant in their own adventures. It is a valuable tool for any therapy or home environment where independence and mobility are encouraged.
-
Rabbit Up video
We spent the morning with Gustav, his sister Nanna and mother Mia, who reminded us of the importance of being able to move about and be independent.
Features
-
Features
Stander and Mobile stander
While meeting all your standing needs, the Rabbit Up offers the independence to explore using the optional driving wheels.
-
Features
Angle adjustable center bar
The Rabbit Up has a simple, easy to use and controlled angle adjustment, making it possible to obtain the best standing position.
-
Features
Quick release wheels
The two driving wheels are equipped with quick release for easy mounting. The wheels are available in a variety of sizes.
-
Features
Camber angling
Rabbit Up gives the possibility to change the camber angle of the driving wheels to enable an optimum fit for the child.
Variants
| Size 1 | Size 1 without driving wheels | Size 2 | Size 2 Without driving wheels | Size 3 | Size 3 without driving wheels | Size 4 | Size 4 without driving wheels | |
|---|---|---|---|---|---|---|---|---|
| Item number | 86212xx-00 | 86212XX-00 | 8622xx-00 | 86222XX-00 | 8632xx-00 | 86232XX-00 | 8642xx-00 | 86242XX-00 |
| Angle of the centre bar (°) | 0-30 | 0-30 | 0-30 | 0-30 | 0-30 | 0-30 | 0-30 | 0-30 |
| Camber angle (°) | 8 | - | 6 | - | 6 | - | 4 | - |
| Floor to foot plate (mm) | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 |
| Height, vertical (mm) | 620 | 700 | 750 | 796 | 800 | 796 | 900 | 926 |
| Inside width (mm) | 325 | 325 | 375 | 375 | 425 | 425 | 425 | 425 |
| Length (mm) | 500 | 500 | 700 | 700 | 800 | 800 | 1000 | 1000 |
| Mass device (kg) | 13.5 | 9 | 15.5 | 10.5 | 16 | 11 | 18.5 | 13.5 |
| Maximum rated load (kg) | 55.5 | 51 | 67.5 | 62.5 | 78 | 73 | 90.5 | 85.5 |
| Maximum user mass (kg) | 40 | 40 | 50 | 50 | 60 | 60 | 70 | 70 |
| Minimum turning diameter (mm) | 850 | 850 | 950 | 950 | 980 | 980 | 1085 | 1085 |
| Overall height (mm) | 670-1000 | 670-1000 | 850-1180 | 850-1180 | 990-13110 | 990-13110 | 1200-1530 | 1200-1530 |
| Overall width (mm) | 635 | 515 | 680 | 550 | 730 | 600 | 720 | 600 |
| Static stability downhill (°) | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 |
| Static stability sideways (°) | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 |
| Static stability uphill (°) | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 |
| User height: floor to axil (mm) | 500-740 | 550-740 | 750-1080 | 750-1080 | 830-1190 | 830-1190 | 960-1420 | 960-1420 |
Washing instructions
The product is CE marked
Options
Accessories
Documents
Download of user manuals are intended for expedient purpose only. The products in reference may be subject to change without prior notice and reader’s discretion is advised to ensure coherence with product version and article number as well as the appropriate translation.
Videos
Camber angling adjustment
How to mount the foot plate on Rabbit Up
How to mount the central brakes
How to change the spindle
