R82 Quokka
The Quokka is a highly functional convertible (rear and forward-facing) child restraint system.
The Quokka is a car seat that offers patients both comfort and maximum safety. It meets a range of postural requirements with an ergonomic design to accommodate a child that weighs from 2.3 kg.
The Quokka can be used in rear facing for a child that weighs from 2,3 kg and in the forward facing orientation for a child that weighs from 10 kg.
The Quokka’s exceptional Spica positioning wedge ensures a casted user is fully supported during transit, kept both upright and stable. The sides of the seat are specially formed to fit legs that are casted or in a brace, while the head and neck are held both secure and comfortable with the adjustable plush head support and multi positional padded 5-point safety harness. The LATCH System comes standard with each Quokka making each car ride a safe fun adventure for the entire family.
The maximum weight of a child including the weight of the cast or brace is 18 kg.
This product is only available in certain markets. Please contact your local R82 contact person or distributor for more information.
Discover
Quokka video
Features
Spica Positioning Wedge
Configuration options
Growth
LATCH system
Variants
| One size | |
|---|---|
| R82 item number | 905371-2 |
| Approximate total user height (mm) | 1041 |
| Back height (mm) | 533 |
| Exterior shell depth (mm) | 384 |
| Exterior shell height (mm) | 597 |
| Exterior shell width (mm) | 406 |
| Head support height (mm) | 165 |
| Head support Height Range Max (mm) | 495 |
| Head support Height Range Min (mm) | 343 |
| Height of shoulder strap slots (mm) | 190, 241, 292, 343 |
| Interior shell depth (mm) | 279 |
| Interior shell height (mm) | 533 |
| Interior shell width (mm) | 279 |
| Maximum user weight (kg) | 18 |
| Minimum user weight - Forward facing (kg) | 10 |
| Minimum user weight - Rear facing (kg) | 2.3 |
| Seat depth (mm) | 279 |
| Seat width (mm) | 279 |
| Total weight (kg) | 7.2 |
Options
Colour
Available in red/black
Red/Black
Spica wedge
The unique Spica Positioning Wedge provides a casted user the ability to obtain an adequately supported fit during transit.
5-Point Safety Harness
The 5-point safety harness is easily adjustable in height and length to fit your child as they grow.
Padded Harness Covers
Padded harness strap cover for additional comfort and support.
Head Support
Provides the child’s neck and head with optimal support for safety and comfort during transit.
Lower Anchors
Top Tether
Documents
Download of user manuals are intended for expedient purpose only. The products in reference may be subject to change without prior notice and reader’s discretion is advised to ensure coherence with product version and article number as well as the appropriate translation.
