R82 High-low:x Frame

The High-low:x Frame is a stable base with a user friendly height adjustment from floor to table height.

The High-low:x Frame is available either as an indoor frame with small lockable castors or as an outdoor frame with large wheels and foot brake.

The frames are available with either gas, power or hydraulic height adjustment. The frames accomodate various seats, e.g. the x:panda seats from R82.

The High-low:x Frame is available in three sizes as indoor version and in two sizes as outdoor version. The High-low:x Frame max load is 100 kg.

Features

Safe transportation in vehicles

Safe transportation in vehicles

The High-low:x Frame, outdoor, complies with the international transit wheelchair standard ISO 7176-19. The High-low:x Frame, outdoor, can be used with seat units that comply with ISO 16840-4
Height adjustment

Height adjustment

The height is adjustable from floor to table height. The frames are available with either gas, power or hydraulic height adjustment
Fixed mounting or interface

Fixed mounting or interface

On the High-low:x size 1 and 2 the seats are mounted into the interface. On size 3 the seats can be mounted either directly onto the High-low:x Frame or by using an interface
Angling of seat base

Angling of seat base

The seat base has an angle range of 40° which helps obtain varied seating positions. The base can be angled from 0 to 30° or from -10° to 20°

Variants and details

Indoor frame, gas, size 1
Indoor frame, gas, size 2
Indoor frame, power, size 1
Indoor frame, power, size 2
Indoor frame, power, size 3
Indoor frame, hydraulic, size 2
Outdoor frame, gas, size 1
Outdoor frame, gas, size 2
Outdoor frame, power, size 1
Outdoor frame, power, size 2
Outdoor frame, hydraulic, size 2
R82 item number 8911603-02 8911605-02 8911603-02EL 8911605-02EL 8911607-02EL 8911606-02 8911613-02 8911615-02 8911613-02EL 8911615-02EL 8911616-02
Footrest to adaptor plate (mm) 50-290 50-290 50-290 50-290 50-290 50-290 50-290 50-290 50-290 50-290 50-290
Length (mm) 690 780 690 780 780 780 1110 960 1110 960 1110
Mass device (kg) 12.5 14 13 16.5 17 16.5 20.5 18 20.5 17.5 20
Max load at transportation (kg) - - - - - - 43 43 43 43 43
Max load (kg) 60 60 60 60 100 60 60 60 60 60 60
Maximum rated load (kg) 74.5 76 75 78.5 119 78.5 82.5 80 82.5 79.5 80
Overall width (mm) 560 620 560 620 620 620 620 620 620 620 620
Seat plane angle (°) (-10) - 30 (-10) - 30 (-10) - 30 (-10) - 30 (-10) - 30 (-10) - 30 (-10) - 30 (-10) - 30 (-10) - 30 (-10) - 30 (-10) - 30
Seat surface height at front edge (mm) 190-615 240-615 170-600 255-600 260-550 215-560 430-590 260-700 330-640 260-700 330-640

Options

The indoor frame is available in 3 sizes - the outdoor frame is available in 2 sizes

Size 1 indoor frame with power

Size 2 indoor frame with power

Size 3 indoor frame with power

x:panda

We recommend; x:panda size 1-2 on frame size 1 x:panda size 3 on frame size 2-3 x:panda size 4 on frame size 3

Stingray

Possible combinations; Stingray size 1-2 on frame size 2

Hydraulic

Gas

Power
