R82 Caribou

The Caribou is a standing frame that supports a prone, upright, or supine standing position.

The tilt function and the extensive accessories selection allows users who have severe limitations in head and trunk control or who experience limitations in their range of motion to adopt the standing position. Thereby the Caribou supports the child to participate in things they value – and it can bridge the disparities between children with and without disabilities.

The Caribou is available in four sizes and suitable for children from approximately 850 mm (33 1/2”) to 1840 mm (72 1/2"). The max. user mass is 100 kg (220 lb).

Features

The Caribou tilts from vertical to horizontal. The horizontal position makes it easier for the carer and less stressful for the user to be placed into position.
The Caribou is designed with a raised frame for easy use of floor hoist.

Easy transfer

The Caribou tilts from vertical to horizontal. The horizontal position makes it easier for the caregiver and less stressful for the user to be placed into position. The Caribou is designed with a raised frame for easy use of floor hoist.
Soft PU material for optimum comfort. The shape can be moulded to the body using additional wedges to shape the PU. The Caribou is designed with smooth edges for better safety and it is easy to clean.

Anatomic design and soft mouldable PU

Soft PU material for optimum comfort. The shape can be moulded to the body using additional wedges to shape the PU. The Caribou is designed with smooth edges for better safety and it is easy to clean.
Caribou has a rage of different accessories.

Interchangeable accessories makes for optimal solutions

Caribou has a rage of different accessories that are easily interchangeable for carers' convenience.
The Caribou is supplied with an easy tilt mechanism, which allows the carer to have both hands free.

Easy tilt

The Caribou is supplied with an easy tilt mechanism, which allows the caregiver to have both hands free.

Standard specifications

Size 1
Size 1 (w/ power)
Size 2
Size 2 (w/ power)
Size 3
Size 3 (w/ power)
Size 4
Size 4 (w/ power)
Item number 860101 860101-EL 860102 860102-EL 860113 860103-EL 860114 860104-EL
Angling (°) 0-87 0-87 0-87 0-87 0-87 0-87 0-87 0-87
Approximate total user height (Inch) 33.5-44 33.5-44 38.5-50.75 38.5-50.75 49.25-61.50 49.25-61.50 60.25-72.50 60.25-72.50
Foot plate angle (°) (-10) - 10 (-10) - 10 (-10) - 10 (-10) - 10 (-10) - 10 (-10) - 10 (-10) - 10 (-10) - 10
Length (inch) 29.5 29.5 36.25 36.25 43.75 43.75 43.75 43.75
Maximum rated load (lbs) 137.7 142.1 194 192.9 248 252.4 302 306.4
Maximum user mass (lbs) 88.1 88.1 132.2 132.2 176.3 176.3 220.4 220.4
Maximum user weight (lbs) 88.1 88.1 132.2 132.2 176.3 176.3 220.4 220.4
Overall height, horizontal (inch) 27.5 27.5 27.5 27.5 31.5 31.5 31.5 31.5
Overall height, vertical (inch) 18-22.5 18-22.5 20.75-25.25 20.75-25.25 26.75-31 26.75-31 34.75-39 34.75-39
Overall width (inch) 20 20 22.5 22.5 25.5 25.5 29.5 29.5
Static stability downhill (°) 5 5 5 5 5 5 5 5
Static stability sideways (°) 5 5 5 5 5 5 5 5
Static stability uphill (°) 5 5 5 5 5 5 5 5
Total mass (lbs) 45.1 49.6 51.8 56.2 67.2 71.7 77.1 81.6

Overall height configuration: Standard product and top plate (measured from the floor)

Options

Available in different colors.

Yellow for size 1

Red for size 2

Blue for size 3

Anthracite grey for size 4

Parted foot supports makes it possible to adjust individual foot heights and angles.

Goes from minus 3 degrees to horizintal position. Sizes 3 and 4 are recommended in the power versions to ease tilting.

Foot operated gas spring

With power actuator
