R82 Flamingo High-low

Flamingo High-low is a modern and comfortable toilet/bathing chair that fits into most bathrooms.

The Flamingo High-low has smooth and stepless height adjustment. The height adjustable feature allows caregivers to perform bathing and hygiene tasks in a convenient and good working position. Furthermore, the function is useful during transfers with a hoist, where it allows the user and caregiver to stay at eye level, providing dignity in the process. The PU inlay provides comfort for the user while the elegant design makes it easy for the caregiver to use. The Flamingo High-low is one of the most versatile products on the market with up to five configurations available. It can be used freestanding with a pan, directly over the toilet and as a shower chair. The seat is also removable for direct mounting on a toilet or in a bath.

Features

The smooth height adjustment allows the Flamingo High-low to adjust from 53 to 74 cm in seat height. Height adjustablity eases transfer from/to the chair and provides optimum working conditions for the carer

Easy adaptation of working conditions

The smooth height adjustment allows the Flamingo High-low to adjust from 20¾ to 28¾" in height. Height adjustablity eases transfer from/to the chair and provides optimum working conditions.
The Flamingo High-low offers simple tilt-in-space and back recline functions. It is very easy to position the user with knees higher than the hips which has been proven very effective for bowel function

Optimum positioning

The Flamingo High-low offers easily operated tilt-in-space and back recline functions and can accommodate positioning of the user with the knees higher than the hips which might have a positive impact on bowel movements.
The Flamingo High-low has easily accessible foot pedals for height adjustment and tilt-in-space. The pedals are equipped with security locks for added safety

Easy to use

The Flamingo High-low has easy accessible foot pedals for height adjustment and tilt-in-space. The pedals are equipped with security locks for added safety.
Flamingo High-low is the perfect choice when bathtimes are more than just a quick dip and scrub. The inlay and the back recline function make it very easy to get comfortable and relaxed

Bathtime is fun and relaxing

Flamingo High-low is the perfect choice when bathtimes are more than just a quick dip and scrub. The PU inlay and the back recline function make it very easy to get comfortable and relaxed.

Standard specifications

Size 1
Size 2
Size 3
Size 4
Flamingo seat size 1
Flamingo seat size 2
Flamingo seat size 3
Flamingo seat size 4
Item number 880401-x 880402-x 880403-x 880404-x 880101 880102 880103 880104
Back width (inch) 7.75 8.75 10.25 11 - - - -
Backrest angle (°) 30 30 30 30 - - - -
Backrest height (inch) 13.75 15 16.5 18.5 - - - -
Effective seat depth (inch) 9.75 11.5 13.75 15.75 - - - -
Footrest to seat distance (inch) 7.75-9.95 9-13.5 11.75-16.5 11.75-16.5 - - - -
Leg to seat surface angle (°) 90-75 90-75 90-75 90-75 - - - -
Length (inch) 25.25 25.25 30 30 10.25 12.5 14.25 16.75
Mass device (lbs) 30.8 31.9 36.3 37.4 5.5 6.5 8.8 9.9
Max load (lbs) 112.4 146.6 173 196 - - - -
Max load, operating force (lbs) 77.1 77.1 121.2 121.2 - - - -
Maximum rated load (lbs) 90.3 - - - 87 121.2 145.5 168.6
Maximum user mass (lbs) 77.1 110.2 132.2 154.3 77.1 110.2 132.2 154.3
Maximum user weight (lbs) 77.1 110.2 132.2 154.3 - - - -
Overall height (inch) 33.75-42.5 36.25-43.75 37-46 40.25-47.25 - - - -
Overall width (inch) 19.75 19.75 22.5 22.5 - - - -
Seat plane angle (°) (-5)-20 (-5)-20 (-5)-20 (-5)-20 - - - -
Seat surface height at front edge (inch) 20.75-29.25 20.75-29.25 20.75-29.25 20.75-29.25 - - - -

Options

The Flamingo PU inlay is available in two different colors

Grey

Blue

Flamingo High-Low has multi-purpose basic functions and designed for independent use, or with assistance.

Directly over the toilet

Directly on a toilet

In the shower

Size 1

Size 2

Size 3

Size 4

The frame is adjustable in height from 53-74 cm. The aluminium frame has a durable waterproof suface and all castors have brakes for safe and stable transfer. The frame comes in two sizes, each available with two sizes of seat mounting.

Height adjustment 53-74 cm

Size 1

Size 2

Documents

Download of user manuals are intended for expedient purpose only. The products in reference may be subject to change without prior notice and reader’s discretion is advised to ensure coherence with product version and article number as well as the appropriate translation.
