Molift Quick Raiser 205
Ergonomic sit-to-stand lift with outstanding transfer capability
The Molift Quick Raiser 205 is a state-of-the-art sit-to-stand lift with outstanding transfer capabilities and exceptional maneuverability. The design encourages a natural movement pattern and fulfils the lifting needs of users with some weight-bearing capacity.
The natural movement pattern
The inclined column encourages a natural movement pattern and fulfils the lifting needs of users up to 452 lbs, with some weight-bearing capacity. The user can feel safe and comfortable in every movement as the lifting experience is the same regardless of the carer, lifting arm or sling.
Molift Quick Raiser 205 is compact, stable and exceptionally easy to maneuver. The lift has a small turning radius and good maneuverability even in tight spaces, thanks to the unique wheel position, angled push rod and outstanding base weight distribution.
The lift fits under most beds and chairs, and the variant with electrically adjustable legs allows accessibility almost anywhere. The fixed leg option enables a very small footprint.
Flexible lifting arm
Ergonomic for the carer
|Specifications common for all sizes|
|Battery||SLA 24V 2,9 Ah||Protection class||IP24|
|Battery charge time (hours)||5||Rated performance||100 lifts/165 lbs|
|Expected Lifetime||30 000 cycles or 10 years||Service software||Molift Service Tool|
|Height (inch)||44.9||Width chassis, legs inner (inch)||8.7|
|Lifting speed 165 lbs (inch/sec)||1.4||Width chassis, legs open inner (inch)||40.4|
|Material||Aluminium, Plastic, Steel||Width chassis, outer (inch)||24.8|
|Maximum user weight (lbs)||452|
|Item number||Length (inch)||Product includes||Total weight (lbs)|
|Molift Quick Raiser 205, Active 4-point lifting arm. Adjustable leg.||M29100||52||Castor size Ø3.9 inch. Standard leg supports.||97|
|Molift Quick Raiser 205, Active 4-point lifting arm. Adjustable legs.||M29100-00||52||Castor size Ø3.9 inch. Alternative leg supports (large).||97|
|Molift Quick Raiser 205, Active 4-point lifting arm. Fixed leg.||M29150||45.9||Castor size Ø2.95 inch. Standard leg supports||93.7|
|Molift Quick Raiser 205, Active 4-point lifting arm. Fixed leg.||M29200-00||45.9||Castor size Ø3.9 inch. Alternative leg supports (large).||93.7|
Download of user manuals are intended for expedient purpose only. The products in reference may be subject to change without prior notice and reader’s discretion is advised to ensure coherence with product version and article number as well as the appropriate translation.
