StarLock
StarLock
In air cell cushions, the combination of pressure redistributing qualities and stability has always been a difficult compromise – With StarLock, you can have both.
Vertical Air Cells
Star cushions feature vertical air cell technology designed specifically for individuals at high risk of pressure injuries. Star’s interconnected vertical air cell design ensures internal cell pressures equalise as the user sits in the cushion. The vertical air cell construction also effectively reduces surface tension and enables excellent envelopment.
Pressure Care with Pressure Redistribution and Postural Support
StarLock is the complete cushion solution for pressure care with pressure redistribution, stability and postural support. And it is available in 5, 7.5, 10 and 13 cm cell heights. Whatever the cell height, the sitting height will always be the same. However, the higher the cell, the greater the pressure redistribution.
The 13 cm cell height is unique to StarLock and offers greater immersion and envelopment.
Shaping, Offloading and Stability
The StarLock cushion, with its StarLock Technology, provides the possibility to lock air into each vertical air cell which makes it possible to create a desired shape, offload localised pressure and increase stability, allowing for individualised postural support.
It can be adjusted and reset again and again, making it very flexible over time.
StarLock can also work as a single air chamber cushion allowing individual setup for optimal pressure redistribution.
Washing instructions
Clean the product with a 70% disinfectant solution.
Hand wash - max. temperature 40 °C/104 °F
Wiping - the product can be wiped clean with a cleaning cloth
Features
-
Features
Shape for the Individual
StarLock technology conforms to the user’s body shape or desired position, which can help by locking the air into each cell. StarLock can meet the individual user´s changing needs for support and shape.
-
Features
Stability
The individual cell locking technology aids stability and allows individualised postural support.
-
Features
Offloading
Locking down cells in a selected area of the cushion can relieve pressure on particularly vulnerable areas.
-
Features
Adjustability
StarLock can be adjusted and reset again and again, making it very flexible over time. The user can remain seated throughout the assessment.
-
Features
Recondition and Reuse
StarLock can always be washed and repaired and adjusted and disinfected as often as you want. Without locking the Lock Pockets, StarLock can also be used as a classic single-chamber cushion.
Variants and details
| Item number | A x B: Cell amount (W x D) | Cell height (mm) | Cell width (mm) | Maximum user weight | Suits wheelchair seat depth (mm) | Suits wheelchair seat width (mm) | Weight (kg) | |
|---|---|---|---|---|---|---|---|---|
| 26 x 26 cm | ESSL20909-1 | 5x5 | 50 | 50 | Unlimited | 240-270 | 220-250 | - |
| 26 x 30 cm | ESSL20911-1 | 5x6 | 50 | 50 | Unlimited | 280-310 | 220-250 | - |
| 26 x 34 cm | ESSL20913-1 | 5x7 | 50 | 50 | Unlimited | 320-350 | 220-250 | - |
| 30 x 26 cm | ESSL21109-1 | 6x5 | 50 | 50 | Unlimited | 240-270 | 260-300 | - |
| 30 x 30 cm | ESSL21111-1 | 6x6 | 50 | 50 | Unlimited | 280-310 | 260-300 | - |
| 30 x 34 cm | ESSL21113-1 | 6x7 | 50 | 50 | Unlimited | 320-350 | 260-300 | - |
| 30 x 39 cm | ESSL21115-1 | 6x8 | 50 | 50 | Unlimited | 360-400 | 260-300 | - |
| 34 x 26 cm | ESSL21309-1 | 7x5 | 50 | 50 | Unlimited | 240-270 | 310-350 | - |
| 34 x 30 cm | ESSL21311-1 | 7x6 | 50 | 50 | Unlimited | 280-310 | 310-350 | - |
| 34 x 34 cm | ESSL21313-1 | 7x7 | 50 | 50 | Unlimited | 320-350 | 310-350 | - |
| 34 x 39 cm | ESSL21315-1 | 7x8 | 50 | 50 | Unlimited | 360-400 | 310-350 | - |
| 34 x 44 cm | ESSL21317-1 | 7x9 | 50 | 50 | Unlimited | 410-450 | 310-350 | - |
| 39 x 30 cm | ESSL21511-1 | 8x6 | 50 | 50 | Unlimited | 280-310 | 360-400 | - |
| 39 x 34 cm | ESSL21513-1 | 8x7 | 50 | 50 | Unlimited | 320-350 | 360-400 | - |
| 39 x 39 cm | ESSL21515-1 | 8x8 | 50 | 50 | Unlimited | 360-400 | 360-400 | - |
| 39 x 44 cm | ESSL21517-1 | 8x9 | 50 | 50 | Unlimited | 410-450 | 360-400 | - |
| 39 x 49 cm | ESSL21519-1 | 8x10 | 50 | 50 | Unlimited | 460-500 | 360-400 | - |
| 39 x 53 cm | ESSL21521-1 | 8x11 | 50 | 50 | Unlimited | 510-550 | 360-400 | - |
| 44 x 34 cm | ESSL21713-1 | 9x7 | 50 | 50 | Unlimited | 320-350 | 410-450 | - |
| 44 x 39 cm | ESSL21715-1 | 9x8 | 50 | 50 | Unlimited | 360-400 | 410-450 | - |
| 44 x 44 cm | ESSL21717-1 | 9x9 | 50 | 50 | Unlimited | 410-450 | 410-450 | - |
| 44 x 49 cm | ESSL21719-1 | 9x10 | 50 | 50 | Unlimited | 460-500 | 410-450 | - |
| 44 x 53 cm | ESSL21721-1 | 9x11 | 50 | 50 | Unlimited | 510-550 | 410-450 | - |
| 49 x 39 cm | ESSL21915-1 | 10x8 | 50 | 50 | Unlimited | 360-400 | 460-500 | - |
| 49 x 49 cm | ESSL21919-1 | 10x10 | 50 | 50 | Unlimited | 460-500 | 460-500 | - |
| 49 x 53 cm | ESSL21921-1 | 10x11 | 50 | 50 | Unlimited | 510-550 | 460-500 | - |
| 53 x 39 cm | ESSL22115-1 | 11x8 | 50 | 50 | Unlimited | 360-400 | 510-550 | - |
| 53 x 44 cm | ESSL22117-1 | 11x9 | 50 | 50 | Unlimited | 410-450 | 510-550 | - |
| 53 x 49 cm | ESSL22119-1 | 11x10 | 50 | 50 | Unlimited | 460-500 | 510-550 | - |
| 53 x 53 cm | ESSL22121-1 | 11x11 | 50 | 50 | Unlimited | 510-550 | 510-550 | - |
| 58 x 44 cm | ESSL22317-1 | 12x9 | 50 | 50 | Unlimited | - | 540-600 | - |
| 58 x 49 cm | ESSL22319-1 | 12x10 | 50 | 50 | Unlimited | - | 540-600 | - |
| 58 x 53 cm | ESSL22321-1 | 12x11 | 50 | 50 | Unlimited | - | 540-600 | - |
| 58 x 58 cm | ESSL22323-1 | 12x12 | 50 | 50 | Unlimited | - | 540-600 | - |
| 26 x 26 cm | ESSL30909-1 | 5x5 | 75 | 50 | Unlimited | 240-270 | 220-250 | - |
| 26 x 30 cm | ESSL30911-1 | 5x6 | 75 | 50 | Unlimited | 280-310 | 220-250 | - |
| 26 x 34 cm | ESSL30913-1 | 5x7 | 75 | 50 | Unlimited | 320-350 | 220-250 | - |
| 30 x 26 cm | ESSL31109-1 | 6x5 | 75 | 50 | Unlimited | 240-270 | 260-300 | - |
| 30 x 30 cm | ESSL31111-1 | 6x6 | 75 | 50 | Unlimited | 280-310 | 260-300 | - |
| 30 x 34 cm | ESSL31113-1 | 6x7 | 75 | 50 | Unlimited | 320-350 | 260-300 | - |
| 30 x 39 cm | ESSL31115-1 | 6x8 | 75 | 50 | Unlimited | 360-400 | 260-300 | - |
| 34 x 26 cm | ESSL31309-1 | 7x5 | 75 | 50 | Unlimited | 240-270 | 310-350 | - |
| 34 x 30 cm | ESSL31311-1 | 7x6 | 75 | 50 | Unlimited | 280-310 | 310-350 | - |
| 34 x 34 cm | ESSL31313-1 | 7x7 | 75 | 50 | Unlimited | 320-350 | 310-350 | - |
| 34 x 39 cm | ESSL31315-1 | 7x8 | 75 | 50 | Unlimited | 360-400 | 310-350 | - |
| 34 x 44 cm | ESSL31317-1 | 7 x9 | 75 | 50 | Unlimited | 410-450 | 310-350 | - |
| 39 x 30 cm | ESSL31511-1 | 8x6 | 75 | 50 | Unlimited | 280-310 | 360-400 | - |
| 39 x 34 cm | ESSL31513-1 | 8x7 | 75 | 50 | Unlimited | 320-350 | 360-400 | - |
| 39 x 49 cm | ESSL31519-1 | 8x10 | 75 | 50 | Unlimited | 460-500 | 360-400 | - |
| 39 x 53 cm | ESSL31521-1 | 8x11 | 75 | 50 | Unlimited | 510-550 | 360-400 | - |
| 44 x 34 cm | ESSL31713-1 | 9x7 | 75 | 50 | Unlimited | 320-350 | 410-450 | - |
| 44 x 39 cm | ESSL31715-1 | 9x8 | 75 | 50 | Unlimited | 360-400 | 410-450 | - |
| 44 x 49 cm | ESSL31719-1 | 9x10 | 75 | 50 | Unlimited | 460-500 | 410-450 | - |
| 44 x 53 cm | ESSL31721-1 | 9x11 | 75 | 50 | Unlimited | 510-550 | 410-450 | - |
| 49 x 39 cm | ESSL31915-1 | 10x8 | 75 | 50 | Unlimited | 360-400 | 460-500 | - |
| 49 x 44 cm | ESSL31917-1 | 10x9 | 75 | 50 | Unlimited | 410-450 | 460-500 | - |
| 49 x 49 cm | ESSL31919-1 | 10x10 | 75 | 50 | Unlimited | 460-500 | 460-500 | - |
| 49 x 53 cm | ESSL31921-1 | 10x11 | 75 | 50 | Unlimited | 510-550 | 460-500 | - |
| 53 x 39 cm | ESSL32115-1 | 11x8 | 75 | 50 | Unlimited | 360-400 | 510-550 | - |
| 53 x 44 cm | ESSL32117-1 | 11x9 | 75 | 50 | Unlimited | 410-450 | 510-550 | - |
| 53 x 49 cm | ESSL32119-1 | 11x10 | 75 | 50 | Unlimited | 460-500 | 510-550 | - |
| 53 x 53 cm | ESSL32121-1 | 11x11 | 75 | 50 | Unlimited | 510-550 | 510-550 | - |
| 58 x 44 cm | ESSL32317-1 | 12x9 | 75 | 50 | Unlimited | - | 540-600 | - |
| 58 x 49 cm | ESSL32319-1 | 12x10 | 75 | 50 | Unlimited | - | 540-600 | - |
| 58 x 53 cm | ESSL32321-1 | 12x11 | 75 | 50 | Unlimited | - | 540-600 | - |
| 58 x 58 cm | ESSL32323-1 | 12x12 | 75 | 50 | Unlimited | - | 540-600 | - |
| 26 x 26 cm | ESSL40909-1 | 5x5 | 100 | 50 | Unlimited | 240-270 | 220-250 | - |
| 26 x 30 cm | ESSL40911-1 | 5x6 | 100 | 50 | Unlimited | 280-310 | 220-250 | - |
| 26 x 34 cm | ESSL40913-1 | 5x7 | 100 | 50 | Unlimited | 320-350 | 220-250 | - |
| 30 x 26 cm | ESSL41109-1 | 6x5 | 100 | 50 | Unlimited | 240-270 | 260-300 | - |
| 30 x 30 cm | ESSL41111-1 | 6x6 | 100 | 50 | Unlimited | 280-310 | 260-300 | - |
| 30 x 34 cm | ESSL41113-1 | 6x7 | 100 | 50 | Unlimited | 320-350 | 260-300 | - |
| 34 x 26 cm | ESSL41309-1 | 7x5 | 100 | 50 | Unlimited | 240-270 | 310-350 | - |
| 34 x 30 cm | ESSL41311-1 | 7x6 | 100 | 50 | Unlimited | 280-310 | 310-350 | - |
| 34 x 34 cm | ESSL41313-1 | 7x7 | 100 | 50 | Unlimited | 320-350 | 310-350 | - |
| 34 x 39 cm | ESSL41315-1 | 7x8 | 100 | 50 | Unlimited | 360-400 | 310-350 | - |
| 34 x 44 cm | ESSL41317-1 | 7x9 | 100 | 50 | Unlimited | 410-450 | 310-350 | - |
| 39 x 30 cm | ESSL41511-1 | 8x6 | 100 | 50 | Unlimited | 280-310 | 360-400 | - |
| 39 x 34 cm | ESSL41513-1 | 8x7 | 100 | 50 | Unlimited | 320-350 | 360-400 | - |
| 39 x 53 cm | ESSL41521-1 | 8x11 | 100 | 50 | Unlimited | 510-550 | 360-400 | - |
| 44 x 34 cm | ESSL41713-1 | 9x7 | 100 | 50 | Unlimited | 320-350 | 410-450 | - |
| 44 x 39 cm | ESSL41715-1 | 9x8 | 100 | 50 | Unlimited | 360-400 | 410-450 | - |
| 44 x 53 cm | ESSL41721-1 | 9x11 | 100 | 50 | Unlimited | 510-550 | 410-450 | - |
| 49 x 39 cm | ESSL41915-1 | 10x8 | 100 | 50 | Unlimited | 360-400 | 460-500 | - |
| 53 x 39 cm | ESSL42115-1 | 11x8 | 100 | 50 | Unlimited | 360-400 | 510-550 | - |
| 53 x 44 cm | ESSL42117-1 | 11x9 | 100 | 50 | Unlimited | 410-450 | 510-550 | - |
| 53 x 49 cm | ESSL42119-1 | 11x10 | 100 | 50 | Unlimited | 460-500 | 510-550 | - |
| 53 x 53 cm | ESSL42121-1 | 11x11 | 100 | 50 | Unlimited | 510-550 | 510-550 | - |
| 58 x 44 cm | ESSL42317-1 | 12x9 | 100 | 50 | Unlimited | - | 540-600 | - |
| 58 x 49 cm | ESSL42319-1 | 12x10 | 100 | 50 | Unlimited | - | 540-600 | 4.100 |
| 58 x 53 cm | ESSL42321-1 | 12x11 | 100 | 50 | Unlimited | - | 540-600 | - |
| 58 x 58 cm | ESSL42323-1 | 12x12 | 100 | 50 | Unlimited | - | 540-600 | - |
| 26 x 26 cm | ESSL51010-1 | 4x4 | 130 | 60 | Unlimited | 240-270 | 220-260 | - |
| 26 x 30 cm | ESSL51012-1 | 4x5 | 130 | 60 | Unlimited | 280-320 | 220-260 | - |
| 26 x 36 cm | ESSL51014-1 | 4x6 | 130 | 60 | Unlimited | 330-380 | 220-260 | - |
| 30 x 26 cm | ESSL51210-1 | 5x4 | 130 | 60 | Unlimited | 240-270 | 270-320 | - |
| 30 x 30 cm | ESSL51212-1 | 5x5 | 130 | 60 | Unlimited | 280-320 | 270-320 | - |
| 30 x 36 cm | ESSL51214-1 | 5x6 | 130 | 60 | Unlimited | 330-380 | 270-320 | - |
| 30 x 41 cm | ESSL51216-1 | 5x7 | 130 | 60 | Unlimited | 390-430 | 270-320 | - |
| 36 x 26 cm | ESSL51410-1 | 6x4 | 130 | 60 | Unlimited | 240-270 | 330-370 | - |
| 36 x 30 cm | ESSL51412-1 | 6x5 | 130 | 60 | Unlimited | 280-320 | 330-370 | - |
| 36 x 36 cm | ESSL51414-1 | 6x6 | 130 | 60 | Unlimited | 330-380 | 330-370 | - |
| 36 x 41 cm | ESSL51416-1 | 6x7 | 130 | 60 | Unlimited | 390-430 | 330-370 | - |
| 36 x 46 cm | ESSL51418-1 | 6x8 | 130 | 60 | Unlimited | 440-480 | 330-370 | - |
| 41 x 30 cm | ESSL51612-1 | 7x5 | 130 | 60 | Unlimited | 280-320 | 380-430 | - |
| 41 x 36 cm | ESSL51614-1 | 7x6 | 130 | 60 | Unlimited | 330-380 | 380-430 | - |
| 41 x 41 cm | ESSL51616-1 | 7x7 | 130 | 60 | Unlimited | 390-430 | 380-430 | - |
| 41 x 46 cm | ESSL51618-1 | 7x8 | 130 | 60 | Unlimited | 440-480 | 380-430 | - |
| 41 x 51 cm | ESSL51620-1 | 7x9 | 130 | 60 | Unlimited | 490-530 | 380-430 | - |
| 41 x 56 cm | ESSL51622-1 | 7x10 | 130 | 60 | Unlimited | 540-580 | 380-430 | - |
| 46 x 36 cm | ESSL51814-1 | 8x6 | 130 | 60 | Unlimited | 330-380 | 430-480 | - |
| 46 x 41 cm | ESSL51816-1 | 8x7 | 130 | 60 | Unlimited | 390-430 | 430-480 | - |
| 46 x 46 cm | ESSL51818-1 | 8x8 | 130 | 60 | Unlimited | 440-480 | 430-480 | - |
| 46 x 51 cm | ESSL51820-1 | 8x9 | 130 | 60 | Unlimited | 490-530 | 430-480 | - |
| 46 x 56 cm | ESSL51822-1 | 8x10 | 130 | 60 | Unlimited | 540-580 | 430-480 | - |
| 51 x 41 cm | ESSL52016-1 | 9x7 | 130 | 60 | Unlimited | 390-430 | 480-530 | - |
| 51 x 46 cm | ESSL52018-1 | 9x8 | 130 | 60 | Unlimited | 440-480 | 480-530 | - |
| 51 x 51 cm | ESSL52020-1 | 9x9 | 130 | 60 | Unlimited | 490-530 | 480-530 | - |
| 51 x 56 cm | ESSL52022-1 | 9x10 | 130 | 60 | Unlimited | 540-580 | 480-530 | - |
| 56 x 41 cm | ESSL52216-1 | 10x7 | 130 | 60 | Unlimited | 390-430 | 530-590 | - |
| 56 x 46 cm | ESSL52218-1 | 10x8 | 130 | 60 | Unlimited | 440-480 | 530-590 | - |
| 56 x 51 cm | ESSL52220-1 | 10x9 | 130 | 60 | Unlimited | 490-530 | 530-590 | - |
| 56 x 56 cm | ESSL52222-1 | 10x10 | 130 | 60 | Unlimited | 540-580 | 530-590 | - |
| 61 x 46 cm | ESSL52418-1 | 11x8 | 130 | 60 | Unlimited | - | 580-640 | - |
| 61 x 51 cm | ESSL52420-1 | 11x9 | 130 | 60 | Unlimited | - | 580-640 | - |
| 61 x 56 cm | ESSL52422-1 | 11x10 | 130 | 60 | Unlimited | - | 580-640 | - |
| 61 x 61 cm | ESSL52424-1 | 11x11 | 130 | 60 | Unlimited | - | 580-640 | - |
FACTS/ User weight/ No limits as long as the correct sized cushion is used for the user.
Material cushion/ High quality latex free gold coloured Neoprene. Adaptable and flame resistant.
Material cover/ Top & sides: 83% Rip Stop Nylon (Non absorbent fabric that aids in evaporating moisture) 17% Lycra. Bottom: Woven polyester fabric coated with polyvinyl compound. (Antimicrobial treated to inhibit growth of odor causing bacteria, mold and mildew.) Flame resistant.
Material incontinence cover/ Top & sides: 78% Nylon 22% Spandex covered with a Polyurethane film. Bottom: Woven polyester fabric coated with polyvinyl compound (see standard cover).
Cleaning - Cushion/ Hand wash with soap, baking soda or vinegar. For disinfection, use 70% disinfectant solution. Cleaning - Covers: Machine wash 60°C, no bleach.
