Molift Air 200
The compact, powerful hoist, optimized for most day-to-day hoisting needs (SWL 205 kg)
Molift Air 200 is the smallest member of the Molift Air family. Combined with the Molift Rail System and Molift slings, Molift Air solves most day-to-day hoisting situations in health care and other patient handling environments.
Comfort and quality
Molift Air 200 combines the need for maximum comfort with efficient and safe hoisting situations. The design and user-friendliness bring exceptional freedom, which enables a single caregiver to perform daily lifting situations, allowing more time for caring for the individual user. For the caregiver, a better working environment is possible without the need for manual lifting. The user experiences a dignified, safe and comfortable lifting.
The flexible hoist
Molift Air 200 is suitable for sitting and horizontal transfers, as well as standing and gait training situations. It is used with fixed ceiling rails but can also be used for portable free-standing systems.
Molift Air 200 is easy to handle during installation and servicing, due to its very low weight and clever quick-release function.
Molift Air 200 offers flexible solutions such as In-Rail Charging (IRC), Propulsion and possibilities for room-to-room transfer. Add to this the safety features, the large lifting interval and the multiple range of sling bars. This hoist is the complete solution for all healthcare segments.
Small hoist - great lifting capacity
Quick release device for trolley
Silent and soft operation
Intuitive hand control
Variants and details
|Specifications for all variants|
|Battery charge time (hours)||6||Material||Aluminium, plastic|
|Expected lifetime||30,000 lifts SWL/10 years||Protection class||IP24|
|Height (mm)||195||Safe working load (SWL) (kg)||205|
|Hoisting speed 75 kg (mm/sec)||60||Weight (kg)||8.6|
|Length (mm)||360||Width (mm)||190|
|Item number||Battery||Battery charger||Hoisting interval (mm)|
|Molift Air 200 - Li battery||M26201||25,6 V LiFePO4 2,4 Ah||100–240 V AC, 40–60 Hz||3000|
|Molift Air 200 - SLA battery||M26200||12 V SLA 2,9 Ah||100–240 V AC, 40–60 Hz||3000|
|Molift Air 200 IRC||M26356||12 V SLA 2.9 Ah||100-240 V AC, 50-60 Hz max 0.5A||2600|
|Molift Air 200 IRC Propulsion||M26358||12 V SLA 2.9 Ah||100-240 V AC, 50-60 Hz max 0.5A||2600|
|Molift Air 200 Propulsion||M26359||12 V SLA 2.9 Ah||100-240 V AC, 50-60 Hz max 0.5A||2600|
