Convaid EZ Rider

The Convaid EZ Rider is a 10° fixed-tilt buggy that provides upright posture to enhance functional positioning.

The Convaid EZ Rider is a popular upright pediatric buggy that is convenient, lightweight, and compact folding. The EZ Rider is made to order to meet each individual requirements. It comes equipped with Convaid’s proprietary self-tensioning seating system, Self-Tensio®, which provides increased seating tolerance and can help promote neutral pelvic positioning. It provides growth capability through its seat depth extension system.

The EZ Rider comes in Cordura upholstery that is removable, washable, and comes in a wide selection of colors. The Convaid EZ Rider is easy to fold for maximal portability, available in sizes 12, 14, 16, and 18 for up to 250-lbs. It comes with a transit option that meets WC19 transport safety standards. It is attractive, highly durable comes with a lifetime guarantee, and is made in the USA.

Features

Zippered seat pockets in seat and back Cordura upholstery for foam inserts.

Upholstery with built-in seat zippers

Allow for foam inserts for additional padding and support.

Tension Adjustable Back

Allows for individual adjustment to the Lumbar and Thoracic sections of the back.

Self-Tensio®

Self-tensio is Convaid’s unique self-tensioning seating system which provides pelvic positioning similar to a solid seating system in an umbrella folding rehab wheelchair.

Variants and details

	Size 12	Size 14	Size 16	Size 18
Folded height (mm)	445	457	432	394
Folded length (mm)	1130	1168	1219	1130
Folded width (mm)	356	343	356	368
Footrest to seat distance (mm)	76-508	76-533	76-559	76-559
Overall height (mm)	965	978	1016	940
Overall length (mm)	914	953	1105	1219
Overall width (mm)	546	584	660	660
Push handle adjustments (mm)	749-1182	737-1194	711-1143	-
Seat back height (mm)	533C	610C	660C	686C
Seat depth (mm)	229-356	279-406	305-432	368-495
Seat to floor (mm)	483	508	508	546
Seat to footplate (mm)	76-508	76-533	76-559	76-559
Seat width (mm)	305	356	406	457
Shoulder strap height (mm)	279-432	356-508	381-533	406-559
Tilt in space tilt angle (°)	10	10	10	10
Total weight (kg)	11	14	14	13
Weight capacity (kg)	34	45	77	113
Weight capacity transit (kg)	30	45	77	77

Documents

Download of user manuals are intended for expedient purpose only. The products in reference may be subject to change without prior notice and reader’s discretion is advised to ensure coherence with product version and article number as well as the appropriate translation.
